Solar Energy Roof Mounting Micro Inverter WiFi On Grid Solar Power System
  • Solar Energy  Roof Mounting Micro Inverter WiFi On Grid Solar Power System
  • Solar Energy  Roof Mounting Micro Inverter WiFi On Grid Solar Power System
  • Solar Energy  Roof Mounting Micro Inverter WiFi On Grid Solar Power System

Solar Energy Roof Mounting Micro Inverter WiFi On Grid Solar Power System

Place of Origin china
Product Details
Place Of Origin:
Guangdong, China
Output Voltage (V):
85-280V
Short Circuit Protection:
YES
DC/AC Side Varistors:
YES
Night Power Consumption (W):
<0.2
DC Reverse-polarity Protection:
YES
Payment & Shipping Terms
Delivery Time
negotiated
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Product Description

Solar Energy Roof Mounting Micro Inverter WiFi On Grid Solar Power System​



Model

PMD-2000W

Maximum input power

2000W

Peak power tracking voltage

48-130V

Min/max starting voltage

48-130V

Maximum DC short-circuit

65A

Maximum input operating current

60A

Output Data

120V

230V

Peak power output

2000W

2000W

Rated output power

1800W

1800W

Rated output current

20A

20A

Rated voltage range

80-160VAC

180-260VAC

Rated frequency range

48-51/58-61Hz

48-51/58-61Hz

Power Factor

>99%

>99%

Max unit per branch circuit

5pcs (single phase)

8pcs(Single phase)

Output Efficiency

120V

230V

Static MPPT efficiency

99.50%

99.50%

Maximum output efficiency

95%

95%

Night time power consumption

<1W

<1W

THD

<5%

<5%

Exteriro & Feature



Ambient temperature range

*- 40℃ ~ 60℃

Dimensions ( L*W*H)

365mm*300mm*40mm

Weight

2.81kg

Waterproof rating

IP65

Cooling

Self-cooling

Communication Mode

WiFi mode

Power transmission mode

Reverse transfer, load priority

Monitoring system

Mobile APP, PC Browser

Electromagnetic compatibility

EN50081.part1 EN50082.Part1

Grid disturbance

EN61000-3-2 Safety EN62109

Grid detection

DIN VDE 1026 UL1741

Certificate

CE

Solar Energy  Roof Mounting Micro Inverter WiFi On Grid Solar Power System 0



FAQ

Q1. Can I have a sample order?
A. Yes, we welcome sample order to test and check quality.

Q2. What about the lead time?
A. Sample needs 3 days, mass production time needs 5-7 weeks, it depends on order quantity.

Q3. Do you have any MOQ limit?
A. Yes, we have MOQ for mass production, it depends on the different part numbers. 1~10pcs sample order is available. Low MOQ, 1pc
for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?
A. It usually takes 5-7 days to arrive. Airline and sea shipping is also optional.

Q5. How to proceed with an order?
A. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our
suggestions.Thirdly customer confirms the samples and places a deposit for formal order. Fourthly We arrange the production.

Q6. Is it OK to print my logo on the product?
A. Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7.Which certificates do you have?
A:We have CE/FCC/ROHS/UN38.3/MSDS ...etc.

Q8.How about warranty?
A:5 year warranty
