6000 Cycles Stackable On Off Grid Energy Storage Solar Lithium Battery 10kwh
  • 6000 Cycles Stackable On Off Grid Energy Storage Solar Lithium Battery 10kwh
6000 Cycles Stackable On Off Grid Energy Storage Solar Lithium Battery 10kwh

6000 Cycles Stackable On Off Grid Energy Storage Solar Lithium Battery 10kwh

Place of Origin china
Product Details
Output Power Range:
5~10 KWh
Dimension (L*W*H):
490*475*270MM
Weight:
55kg
Protection Class:
IP65
Voltage:
51.2V Or Customized
Capacity:
5120Wh/100ah
Highlight:

Stackable On Off Grid Energy Storage

,

6000 Cycles Off Grid Energy Storage

Payment & Shipping Terms
Minimum Order Quantity
negotiated
Price
negotiated
Delivery Time
negotiated
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Product Description

6000 Cycles Stackable On Off Grid Energy Storage Solar Lithium Battery 10kwh

Products Description
Electrical
Characteristics

Item
Specification
Nominal Voltage
51.2V
Nominal Capacity
100AH
Energy
5120WH
Internal Resistance
≤30MΩ
Cycle Life
＞6000cycle
Months self Discharge
<3%
Efficiency of charge
100%@0.2C
Efficiency of Discharge
96%-99%@1C
Standard Charge
Charge Voltage
58.4±0.2V
Charge Mode
0.2C to 58.4V, then 58.4V,charge current 0.02C(CC/CV
Charge Current
50A
Max.Charge Current
100A
Charge Cut off Voltage
58.4V±0.2V
Stancard Discharge
Continuous Current
100A
Max. Pulse Current
300A(30S)
Discharge Cut off Voltage
40V
Environmental
Charge Temperature
0℃ to 45℃ (32F to 113F) @60 25% Relative Humidity
Discharge Temperature
-20℃ to 60℃ (-4F to 140F) @60± 25% Relative Humidity
Storage Temperature
0℃ to 40℃ (32F to 104F) @60± 25% Relative Humidity
Water Dust Resistance
IP65
Mechanical
Cell & Method
3.2V100AH-16S1P
Shell Material
Iron shel
Dimensions (in./mm.)
635*400*192MM
Weight (lbs./kg.)
46.3KG
Terminal
100A through terminal
Protocol (optional)
RS485/RS232/CAN
BMS




6000 Cycles Stackable On Off Grid Energy Storage Solar Lithium Battery 10kwh 0
6000 Cycles Stackable On Off Grid Energy Storage Solar Lithium Battery 10kwh 1

6000 Cycles Stackable On Off Grid Energy Storage Solar Lithium Battery 10kwh 2
6000 Cycles Stackable On Off Grid Energy Storage Solar Lithium Battery 10kwh 3
Our Advantages
6000 Cycles Stackable On Off Grid Energy Storage Solar Lithium Battery 10kwh 4
Packing & Shipping
6000 Cycles Stackable On Off Grid Energy Storage Solar Lithium Battery 10kwh 5
FAQ
Q1:Can I get some samples to test before placing the order? How many days about it? Is sample free of charge?
A: Yes, It’s 3 days for our stock one, and around 7-15 working days for customized, it depends on the customer’s requirement. It’s charged sample fee and freight together.

Q2: What is MOQ for logo printing?
A: Normally MOQ 1 set as trial order about our existing stock or 10 sets for customized ones. We accept OEM&ODM about product.

Q3: What is your payment term?
A: T/T, Paypal, Credit Card, Western Union are available.

Q4: How about the quality about the products?
A:We will offer 3 years warranty about energy storage, 5-12 years about solar system,
and we 'll test all goods and send you test reports before out of factory.

Q5:Do you have any certifications of products?
A: We have ISO9001:2000, UN38.3,UL Report, FCC, PSE, METI, CE, RoHS, MSDS.

Q6: Are you a manufacturer or trading company?
A: We are a professional manufacturer. Both OEM & ODM service can be accepted.

Q7: Where is your main market?
A: Most of our customers are from USA, United States, Germany, Japan, France, South Africa, Middle East and many other European and Southeast Asian countries.
