48100 Lithium Ion Battery Pack Rechargeable Base Station Battery
Product parameters
|
|
|
|
|
Configuration
|
1P15S
|
|
|
Rated Capacity
|
100Ah
|
25℃±2℃,0.2C constant current discharging,40.5V cut off
|
|
Rated Voltage
|
48V
|
|
|
Standard Charge Current
|
20A(0.2C)
|
|
|
Max Continuous Charge Current
|
50A(0.5C)
|
|
|
Max Charge Current
|
100A(1C)
|
Requirement: 1 cycle/day
|
|
Charge Cut Off Voltage
|
44-54V
|
|
|
Standard Discharge Current
|
20A(0.2C)
|
0.2C CC(Constant Current)discharge, cut off 40.5V.
|
|
Max Continuous Discharge Current
|
50A(0.5C)
|
Continuous 50A discharge
|
|
Max Pulse Discharge Current
|
100A(1C)
|
25℃±3℃,≤1s
|
|
Working Temperature (charge)
|
0℃~55℃
|
0℃-10℃:continuous 20A(max)charge 10℃-45℃: continuous 50A(max)charge 45℃-55℃:continuous 20A(max)charge
|
|
Working Temperature (discharge)
|
-20℃~55℃
|
|
|
Storage temperature
|
-20℃～ 45℃
|
(short term) Within 1 month
|
|
Storage temperature
|
0℃～35℃
|
(long term) Within 1 year
|
|
Battery Weight
|
45±2Kg
|
Subject to actual conditions
|
|
Battery Impendence
|
≤30mΩ
|
50%SOC,AC 1kHz
|
|
IP rating
|
IP20
|
|
|
Charge/Discharge Efficiency
|
≥99%
|
Charge/discharge efficiency in Wh (round trip efficiency) at 0.2C charge and discharge current,25℃.
|
System advantages:
1, Mature and reliable topology design, optimized peak shaving and valley filling strategies at the systemlevel, configurable reverse power detectionto pre-vent reverse power transmission
2,Customized energy storage scheme design, strong capacity matching ability, advanced liquid cooling andthermal management mode,large energy storage ca-pacity in smaller areas
3,lntegrated design, integrated design for fire hydrant and thermal management, rapid deployment, andflexible expansion based on user side power require-ment
4,Cloud platform management of energy storage system,big data demand analysis, formulation of optimal re-sponse strategy, calculation of multi scenario econom-ic model, formulation of optimal revenue strategy
Applications
1,Solar unattended microwave relay station
2,optical cable maintenance station,
3,broadcast/communication/paging power system, etc.
4,Oil pipeline and reservoir gate cathodic protection solar power system,
5,oil drilling platform living and emergency power supply,
6,ocean detection equipment,
7,meteorological/hydrological observation equipment, etc.
FAQ
Q1: Are you a factory or a trading company?
A1: we are a professional rechargeable lithium-ion battery and LifePO4 battery manufacturer, welcome to visit.
Q2: What kind of certificates do you have?
A2: We can provide ISO9000,CE, ROHS, FCC, IEC62133, MSDS, UN38.3 and so on , if your quantity is big.
Q3: Do you accept OEM/ODM?
A3: Yes,it is avaliable.
Q4: What is your lead time for the mass production?
A4: about 25-30 days depending on different items after getting down payment and confirmation about the samples.
Q5: Are you battery real capacity?
A5: All of our battery cells with Grade A,100% new and real capacity.
